UE压力开关H100-183-XD002-XP112浓盐水压力控制器 高氯离子防腐哈氏合金HC
系列描述
H100型：一个单刀双掷输出；NEMA 4X外壳，环氧涂层；内部可调，有参考刻度
J120型：一个单刀双掷输出，环氧涂层外壳，外部可调，有参考刻度；一个电气接口

H100-183 H100-184 H100-185 H100-186 H100-188 H100-189

H100-483 H100-484 H100-486 H100-486 H100-488 H100-489

J120-183 J120-184 J120-185 J120-186 J120-188 J120-189

J120-483 J120-484 J120-486 J120-486 J120-488 J120-489

XD002:开关接液膜片材质哈氏合金(HC)

XP112:开关压力接口材质为材质哈氏合金(HC)
应用
·泵和压缩机
·流体动力/液压设备
·临界处理装置功能的极限保护
·防火系统
·热跟踪和低温保护
·温度控制系统
型号及参数
型号      可调整设定范围                              死区                                  zui大压力               耐压**
Model   Adjustable Set Point Range        Deadband                         Over Range            Proof
             Low end of range on fall;                                                       Pressure*             Pressure**
             High end of range on rise range span range span
          psi                       bar                  psi                 bar                       psi       bar           psi        bar
316L stainless steel diaphragm (optional Hastelloy® C or Monel®); Viton® GLT O-Ring (optional Kalrez®, Silicone, Ethylene Propylene, or Aflas®); 316
stainless steel 1/2” NPT (female) pressure connection (optional Hastelloy® C or Monel®), large 0.72” orifice for clean-out purposes. Models 188 and
189 have a 316L stainless steel 1/2” NPT (female) pressure connection (NACE MR-0175 compliant)
183    1 to 20           0,1 to 1,4         0.3 to 2.5     20,7 to 172,4 mbar    500       34,5       1000     68,9
184    2 to 50           0,1 to 3,4         0.3 to 3        20,7 to 206,8 mbar    500       34,5       1000     68,9
185    4 to 100         0,3 to 6,9         0.5 to 6        34,5 to 413,7 mbar    500       34,5       1000     68,9
186    8 to 200         0,6 to 13,8       1 to 11          0,1 to 0,8                  500       34,5       1000     68,9
188    50 to 1000     3,4 to 68,9       25 to 125     1,7 to 8,6                 2000     137,9     7000     482,6
189    250 to 3500   17,2 to 241,3   50 to 300     3,4 to 20,7               4000      275,8    7000     482,6
