Product introduce
H100-184-XD002-XP112美国UE压力开关 全HC接口隔膜片 适用工业污水/废水
哈氏合金C防腐开关型号(氯离子含量高的废水等)
H100-183-XD002-XP112-1/2NPTF,范围:0.1~1.4bar
H100-184-XD002-XP112-1/2NPTF,范围:0.1~3.4bar
H100-185-XD002-XP112-1/2NPTF,范围:0.6~6.9bar
H100-186-XD002-XP112-1/2NPTF,范围:0.6~13.8bar
H100-188-XD002-XP112-1/2NPTF,范围:3.4~68.9bar
H100-189-XD002-XP112-1/2NPTF,范围:17.2~241.3bar
常规UE开关-316L不锈钢压力开关
H100-183 H100-184 H100-185
H100-186 H100-188 H100-189
特点
1,H100系列为不防爆系列。外壳防护等级IP66.
2,适用于高腐蚀性介质,比如污水,工业废水,RO反渗透水泵进出口等。
3,膜片和接头材质可选:316L,哈氏合金C,锰乃尔等。
4,螺纹安装方式,快速,经济,简约等优势。
型号及参数
型号 | 可调整设定范围 | 死区 | zui大压力 | 耐压** | ||||
Model |
Adjustable Set Point Range Low end of range on fall; High end of range on rise range span range span |
Deadband |
Over Range Pressure* |
Proof Pressure** |
||||
psi | bar | psi | bar | psi | bar | psi | bar | |
316L stainless steel diaphragm (optional Hastelloy® C or Monel®); Viton® GLT O-Ring (optional Kalrez®, Silicone, Ethylene Propylene, or Aflas®); 316 stainless steel 1/2” NPT (female) pressure connection (optional Hastelloy® C or Monel®), large 0.72” orifice for clean-out purposes. Models 188 and 189 have a 316L stainless steel 1/2” NPT (female) pressure connection (NACE MR-0175 compliant) |
||||||||
183 | 1 to 20 | 0,1 to 1,4 | 0.3 to 2.5 | 20,7 to 172,4 mbar | 500 | 34,5 | 1000 | 68,9 |
184 | 2 to 50 | 0,1 to 3,4 | 0.3 to 3 | 20,7 to 206,8 mba | 500 | 34,5 | 1000 | 68,9 |
185 | 4 to 100 | 0,3 to 6,9 | 0.5 to 6 | 34,5 to 413,7 mbar | 500 | 34,5 | 1000 | 68,9 |
186 | 8 to 200 | 0,6 to 13,8 | 1 to 11 | 0,1 to 0,8 | 500 | 34,5 | 1000 | 68,9 |
188 | 50 to 1000 | 3,4 to 68,9 | 25 to 125 | 1,7 to 8,6 | 2000 | 137,9 | 7000 | 482,6 |
189 | 250 to 3500 | 17,2 to 241,3 | 50 to 300 | 3,4 to 20,7 | 4000 | 275,8 | 7000 | 482,6 |
